Dimension

275 x 180 x 40mm

Screen

10.1" touch screen; 700nits LED screen

Power Supply

9–36 V

Pixel

1280 * 800 pixels

Storage

2G RAM, 8G ROM

Operating Temperature

-20℃ - 70℃

Storage Temperature

-40℃ - 85℃

Waterproof & Dustproof

IP65

Wi-Fi Configuration

2.4GHz frequency band;
Frequency range: 2.4GHz-2.5GHz,
Output power:14dB±1.5dB

Access Port

Main Wiring Harnessx2, Radiox1,
Type-Cx2, SIM Cardx1,

Constellations

GPS: L1C/A, L1C, L2P(W), L2C, L5
GLONASS: L1, L2
BDS: B1I, B2I, B3I, B1C, B2a
Galileo: E1, E5a, E5b
QZSS：L1, L2, L5

Satellite Corrections

SBAS: WAAS, EGNOS, MSAS

Dimension

162 * 64.5mm

Operating Temperature

-20℃ - +70℃

Storage Temperature

-40℃ - +85℃

Waterproof & Dustproof

IP66

Operation Voltage

9–36 V

Acceleration Accuracy

0.5mg

Operation Current

＜300mA

Gyroscope Accuracy

0.1°/s

Roll and Pitch Angle

0.2°
